Key Advantages & System Highlights
Space Saving
- Slim wall-mounted design minimizes floor space requirements.
- Ideal for space-constrained data center environments in Dubai.
Easy to Deploy
- Front air outlet supports flexible wall-height installation.
- Quick-connect copper piping enables faster installation.
High Reliability
- Premium components and optimized design ensure reliable operation.
- Built for continuous thermal management of critical IT environments.
Product Features & Technical Specifications
Sustainable Energy Efficiency
- Inverter compressor and EC fan provide precise temperature control.
- Optional indirect free cooling helps reduce cooling energy consumption.
- Outdoor-unit compressor design minimizes noise for improved suitability in mini data centers and IT spaces.
Intelligent Control System
- Smart control system with real-time sensor data and intelligent control logic.
- Digital control of major components for optimized performance and flexible operation.
- Stores 1,000+ alarm records and 7-day pressure and temperature history.
- Supports Web, SNMP, Modbus, BACnet, Email, Dry Contact, and IPv6 monitoring.
- Master/Slave, Master Control, and Force Working modes for flexible system operation.
- Built-in web server for remote monitoring and control from computers and mobile devices.
- Automatic restart after power restoration following a blackout.
- Designed for reliable operation in Dubai and UAE data center environments.
Outdoor Condenser
- IP55-rated electrical box with efficient finned heat-transfer design.
- Optional anti-corrosion coating for harsh environmental conditions.
- EC fan with stepless speed control for efficient operation.
- Internally threaded piping and quick connections support faster installation.
Key Components
Inverter Compressor
- Automatically adjusts cooling capacity according to heat load.
- Improves energy efficiency during partial-load operation.
- Supports operation in ambient temperatures up to 55°C with R134a refrigerant option.
EC Fans
- Precisely adjust airflow according to cooling demand.
- Variable-speed operation helps reduce energy consumptio
Electronic Expansion Valve
- Precisely regulates refrigerant flow for efficient cooling.
- Helps reduce compressor and pump power consumption.
Dynamic Actuator
- Intelligent controller continuously monitors system performance.
- Automatically adjusts component output for optimized and balanced operation.
